EJOT H1 8m Hammer Fixing / Metal Pin – Box of 100

View similar products:

  • Applications
    • Approved for all material classes (A, B, C, D, E)
    • For use with all insulation material types
    • For surface fixed installation
    • With European Technical Assessment (ETA)
  • Properties
    • Approved for concrete, solid and perforated masonry
    • Solid steel nail (break-proof)
    • Low profile washer face
    • Plastic injection element to reduce thermal transmission (0,001 W/K)
    • Can be used with additional spreader washers e.g. VT90, SBL140
    • Short embedment depth, reduced drilling
    • High loads for your security
    • Economic anchor usage
    • Pre-mounted nail for quick installation
    • Optimised anchor expansion zone for higher load bearing
    • Increased length spectrum up to 355 mm
  • Technical specifications
    • Anchor diameter: 8 mm
    • Washer diameter: 60 mm
    • Drill hole depth h
    • material class A, B, C, D ≥ 35 mm
    • material class E ≥ 55 mm
    • Embedment depth h
    • material class A, B, C, D ≥ 25 mm
    • material class E ≥ 45 mm
    • Point thermal transmission X: 0.001 W/K
    • Use categories acc. to ETA: A, B, C, D, E
    • European Technical Assessment: ETA-11/0192
Rated 4.6 on Google

SKU: N/A

delivery   Order within to get it

From:
£23.57 + VAT
£28.28 inc. VAT

Need some help? Ask a Question

Click and collect plastering supplies in Cheltenham within 1 hour
Back to top

Product Attributes

Below you will find details about this product.
Can’t find what you are looking for, or need some help? Ask us a question here or call us on 01242 236383

Size

95mm, 115mm, 135mm, 155mm, 175mm, 195mm, 215mm, 235mm, 255mm
